MultiOne 2 Series User Manual

Self-moving compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 2 Series
Instruction manual (Translation of original instructions)
CM170003EN - 16.02.17 - 04 (11.07.18)
31/70
MultiOne SRL
4.8 Emissions
4.8.1 Sound level
The sound level detected by a running machine, without attachment and the following level were noticed.
Model 2.3
Engine rpm* 3000
Level A - weight emission sound pressure in the operator place (LpA) (without cabin) db(A) 85
Level A - weight emission sound pressure in the operator place (LpA) (with cabin) db(A) 85
Guaranteed sound power level (LwA) db(A) 100
(*) as prescribed by the manufacturer for the static test (adjusted in relation to the translation test)
TAB. 15
WARNING
IT IS COMPULSORY TO USE NOISE-CANCELING HEADSETS.
THERE IS RESIDUAL RISK N. 5 (SEE PAR. 3.2).
4.8.2 Vibrations
The vibration level has been detected with the machine running and the operator sitting in the driving seat.
Model 2.3
Rpm rpm 3600
Vibrations m/s
2
0,3
TAB. 16
4.9 Personal protective equipment
Sign PPE compulsory for all authorised operators Sign PPE compulsory for all authorised operators
Hand protection (protective gloves from the
mechanical risk and the risk of burns).
Face protection (protective mask from mechanical
risk).
(Only for some attachment if it is indicated on the
attachment itself through a special adhesive and on
instruction manual.
Protection of the feet (shoes with reinforced toe and
non-slip).
Auditory system protection (anti-noise headsets).
Body protection (protective clothing from
mechanical risk).
TAB. 17
WARNING
PLEASE REFER TO THE ASSEMBLED ATTACHMENT MANUAL TO MAKE SURE FOR POSSIBLE OTHER COMPULSORY PPE.
DESCRIPTION OF THE MACHINE -4
