11.7 Slope guide
FIG. 44
FOLD ALONG DOTTE LINE
THIS IS A 15 DEGREES SLOPE
DO NOT TRAVEL ACROSS OR UP AND DOWN
A SLOPE GREATER THAN 15 DEGREES
SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION
OF A COMPACT UTILITY LOADER WITH AN AT TACHMENT
DO NOT REMOVE THIS PAGE FROM MANUAL
15 DEGREES MAX.
1. Fold this page along dotted line indicated above. DO NOT remove the page
from the manual.
2. Hold page before you so that its left edge is vertically parallel to a tree
trunk or other upright structure.
3. Sight across the fold in the direction of the hill slope you want to measure.
4. Compare the angle of the fold with the slope of the hill.
1
6
T
H
I
S
I
S
A
1
5
DE
G
R
E
E
S
LOP E
DO NO TTRAVE LACROS SORUP AND DOWN
ASLOPE GRE AT ER THAN 15 DEGREE S
To avoid serious injury , operate your unit up and down
the face of slopes.
Travel across slopes with great caution.
Do not operate on slopes greater than 15 degrees.
Make turns gradually to prevent tipping or loss of control.
Exercise extreme caution when changing direction on
slopes.
Control of the machine may be aected by installed
attachments.
Reduce travel speed on slopes.
Read and understand all Warnings and Operating
Instructions in the Operator’s Manual .
WARNING
When driving on slopes, keep the boom and load near to the
ground as much as possible. Rising the boom and/or the load
will decrease the machine stability consistently. Use great caution.
