MultiOne 2 Series - Cabin Commands

Self-moving compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 2 Series
MultiOne SRL
Instruction manual (Translation of original instructions)
CM170003EN - 16.02.17 - 04 (11.07.18)
20/70
4.3.3 Cabin commands
1
3
2
4
5
FIG. 5
Ref. Name Function
1 Cabin light switch
Two-position switch controls the light in the cabin:
• Pos. “0”: cabin light off.
• Pos “1”: cabin light on.
2 External door handle External handle with lock and key. Pulling the lever allows the opening of the door of the cabin.
3 Wiper switch
Two-position switch controls the wiper:
• Pos. “O (OFF)”: wiper off.
• Pos “I (ON)”: wiper on.
4 Inside door handle Inside handle, pulling the lever allows the opening of the door of the cabin.
5
Filler cap of windscreen
washer tank
It allows refilling of the tank.
TAB. 7
4- DESCRIPTION OF THE MACHINE
