Self-moving compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 2 Series
Instruction manual (Translation of original instructions)
CM170003EN - 16.02.17 - 04 (11.07.18)
15/70
MultiOne SRL
4.3 Control devices
FIG. 3
21
5
6
3
4
Ref. Part Function
1 Steering wheel The wheel allows to change direction during the machine operating.
2 Ignition lock key
By Key on and turned to the right carries out respectively:
• Position “0”: machine off.
• Position “1”: power to control panel.
• Position. “2”: starting the machine.
cont.
DESCRIPTION OF THE MACHINE -4
