Self-moving compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 2 Series
MultiOne SRL
Instruction manual (Translation of original instructions)
CM170003EN - 16.02.17 - 04 (11.07.18)
22/70
4.5 Intended use
Range of applications Agriculture, gardening nurseries and gardening, building, road yards and industry.
Location of use Outside the buildings, in a sufficiently lit place suitable to the laws in the country of use in safety.
Intended use The intended use is determined by the type of assembled attachment.
Operators in charge of use
Only one authorised operator qualified with the described professional technical requirements
(see par. 1.6.1).
TAB. 9
4.5.1 Use limits and technical data
4.5.1.1 Machine
Model 2.3
Code C951027
Length MAX. mm 2049
Width MAX. mm 1035
Height MAX. mm 1948
Steering radius mm 700 / 1698
Speed MAX. km\h 15
Machine weight without accessories kg 700
Standard tyres 20x8.00-10
Tyre model Tractor
Oil tank capability litres 19
Working pressure bar 180
Type of mineral hydraulic oil VG 46
Hydraulic pumps N. 3
Hydraulic flow litres/min 42
TAB. 10
4.5.1.2 Engine
Model 2.3
Fuel Petrol
Cylinders Nr.. 2
Cooling air
Power kW/HP 18,6/25
MAX. speed rpm 3600
Tank capacity litres 36
Battery Ah 40
Voltage (DC) V 12
TAB. 11
WARNING
FOR FURTHER TECHNICAL DATA REFER TO ENGINE MANUAL ENCLOSED.
4- DESCRIPTION OF THE MACHINE
