MultiOne 2 Series User Manual

Self-moving compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 2 Series
MultiOne SRL
Instruction manual (Translation of original instructions)
CM170003EN - 16.02.17 - 04 (11.07.18)
56/70
9.7.7 Suction oil filter change
To change the hydraulic oil filter proceed as follows:
1) Put the machine in “safety state” (see par. 9.2).
2) Open the engine cover (see par. 9.4).
3) Drain all hydraulic oil from the oil tank (see par. 9.7.8).
4) Remove the clamp (FIG. 35 - Ref. 3) that fix the suction filter (FIG. 35 - Ref. 1).
5) Loosen the clamps (FIG. 35 - Ref. 2) of the hydraulic hoses.
6) Replace the suction filter (FIG. 35 - Ref. 1) with a new original part.
7) Insert the hydraulic hoses and fix them with the clamps (FIG. 35 - Ref. 2).
8) Fix the suction filter with the clamp.
9) Reinstall the engine cover (see par. 9.4).
10) Proceed with the oil change (see par. 9.7.8).
ATTENTION
THE USED FILTER MUST BE DISPOSED OF IN ACCORDANCE TO THE LAWS IN FORCE IN THE COUNTRY WHERE THE MACHINE
IS USED.
FIG. 35
2 3 21
9- MAINTENANCE
