MultiOne 2 Series User Manual

Self-moving compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 2 Series
MultiOne SRL
Instruction manual (Translation of original instructions)
CM170003EN - 16.02.17 - 04 (11.07.18)
46/70
8.3.8 Parking brake
To insert the parking brake proceed as follows:
1) Pull the parking brake lever (FIG. 25 - Ref. 1) backward and lock it by pushing it to the Left.
2) Inserting the brake it is necessary to hear the click insertion.
3) Move slightly the machine back and forth to cause the blocking of the wheels.
To disengage the parking brake proceed as follows:
1) Unlock the the parking brake lever (FIG. 25 - Ref. 2) by moving it to the right and forward.
2) Move slightly the machine back and forth to cause the unlocking of the wheels.
FIG. 25
21
8.3.9 Refuelling
When the fuel level warning light comes (see par. 4.3.1) on it is necessary to supply proceeding as follows:
1) Put the machine in “safety state” (see par. 9.2).
2) Go onto place C (see FIG. 2).
3) Unscrew the tank cap counterclockwise (FIG. 26 - Ref. 1).
4) Refuelling, if necessary use a funnel to avoid spilling fuel.
5) Completed filling screw the fuel cap clockwise.
DANGER
IT IS FORBIDDEN TO MAKE REFUELLING OPERATIONS WHILE SMOKING AND/OR NEARBY IN PROXIMITY OF FLAMES.THERE IS
FIRE AND/OR EXPLOSION DANGER.
8- OPERATION
