Self-moving compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 2 Series
Instruction manual (Translation of original instructions)
CM170003EN - 16.02.17 - 04 (11.07.18)
41/70
MultiOne SRL
8.3.3.2 Moving on public roads
Check the machine is approved for use on public roads.
ATTENZIONE
IT IF FORBIDDEN THE USE OF THE MACHINE ON ROAD WITHOUT APPROVAL IN COMPLIANCE WITH THE LAWS IN FORCE IN THE
COUNTRY OF USE.
IT IS FORBIDDEN TO TOW ANY ATTACHMENT AND/OR OTHER MEANS USING THE TOW HOOK, SUPPLIED ON REQUEST BY THE
MANUFACTURER, ON PUBLIC ROADS ALSO USING MACHINES APPROVED FOR ROAD CIRCULATION. IT IS FORBIDDEN TO TOW
ANYTHING ON PUBLIC ROADS.
When handling the machine on public roads is required to lock the lift arm. The machine is equipped with two valves to interrupt the
flow of hydraulic oil to the cylinder of the lifting arm.
1) Retract the arm.
2) Move the attachment, if mounted on the universal attachment plate at a height of 20 cm from the ground.
3) Turn off the machine (see par. 8.3.7).
4) Close the two valves to block the lifting arm, placed in the vicinity of the lifting cylinder of the arm. The valves are closed when
the respective levers are perpendicular to the tube hydraulic oil.
5) Proceed to move on public roads.
To unlock the boom proceed as follows:
1) Turn off the machine (see par. 8.3.7).
2) Open the two valves to unlock the lift arm. The valves are open when the levers are parallel to the respective tube hydraulic oil.
8.3.4 Assembly of the attachment
DANGER
IT IS FORBIDDEN TO ASSEMBLY NON SUITABLE OR NON ORIGINAL ATTACHMENTS TO THE MACHINE.
WARNING
IT IS COMPULSORY TO READ THE MANUAL OF ATTACHMENT INSTRUCTIONS BEFORE PROCEEDING THE ASSEMBLY,
DISASSEMBLY AND USE OF THE ATTACHMENT.
WARNING
THERE ARE RESIDUAL RISKS N. 1 AND N. 3 (SEE PAR. 3.2).
OPERATION -8
