2.2 Troubleshooting with Error Messages VJ1324E-M-02
2.2.3 Errors Requiring Reboot P.2-26
7 E070 Err CR
Timeout
A timeout is
detected in the
Head shift
amount (Y-axis)
during printer
operation.
Displayed when
Carriage has not
reached the
designated
position.
1. Check error history from "Test: Record" of self-
diagnosis function.
-
"5.5.9 Record Menu" p.5-18
2. Move carriage in both directions while the printer is
turned off, and check if there is any position where
carriage does not move smoothly.
Clean and lubricate CR rail roller guide.
"7.5 Lubrication/Bonding" p.7-
7
3. Set the number of endurance running cycles to 50 or
more from "Life1 : CR motor" of self-diagnosis
function, and check if "CR time out" occurs.
• Check the connection of following
connectors.
MAIN board:
• CR motor relay Assy
• CR_FFC
CR board:
• CR_FFC connector
"3.4.4 Replacing MAIN Board
Assy" p.3-42
"5.12 Endurance Running
Menu" p.5-71
"3.7.4 Replacing CR Board
Assy" p.3-101
4. Check if T fence is contaminated or worn out. • If grease or dust collect: Wipe fence with
a dry cloth.
• If ink deposit presents: Wipe it off with
cloth dampened with neutral detergent.
• If contamination or deposit is too heavy:
Replace T fence.
"3.6.7 Replacing T Fence, T
Fence Spring Assy" p.3-93
5. Check "Encoder: CR" from "Check: Test” -"Test5:
Encoder" of self-diagnosis function.
If NG:
a) Check the following cable connection:
• CR board Assy connector.
b) Replace the following parts:
•T fence
• CR motor Assy
• CR board Assy
• CR_FFC
"3.7.4 Replacing CR Board
Assy" p.3-101
"3.11.3 Replacing CR_FFC"
p.3-154
6. MAIN board Assy may be damaged. Replace MAIN board Assy . "3.4.4 Replacing MAIN Board
Assy" p.3-42
No. Message Symptoms Check Item Action Reference
To Next Page
