2.2 Troubleshooting with Error Messages VJ1324E-M-02
2.2.3 Errors Requiring Reboot P.2-27
8 E072 Err
CR Current
E074 Err
CR2 Current
E092 Err
CR Over Load
An overload
condition is
detected in CR
motor (Y-axis)
during printer
operation.
1. Check error history from "Test: Record" of self-
diagnosis function.
-
"5.5.9 Record Menu" p.5-18
2. Move carriage in both directions while the printer is turned
off, and check if there is any position where carriage does not
move smoothly.
Clean and lubricate CR rail roller guide. "7.5 Lubrication/Bonding" p.7-
7
3. Set the number of endurance running cycles to 50 or more
from "Life1 : CR motor" of self-diagnosis function, and check
if "CR Current" or “CR2 current” occurs.
• Check the connection of the following
connectors.
MAIN Board Assy ：
• CR motor relay Assy connector
• CR_FFC connectors
CR board Assy ：
• CR_FFC connectors
"3.4.4 Replacing MAIN Board
Assy" p.3-42
"5.12 Endurance Running
Menu" p.5-71
"3.7.4 Replacing CR Board
Assy" p.3-101
4. Check if T fence is contaminated or worn out. • If grease or dust is adhered: Wipe T fence with a
dry cloth.
• If ink is adhered: Wipe it off lightly with a cloth
dampened with neutral detergent.
• If contamination or deposit is too heavy: Replace
T fence.
"3.6.7 Replacing T Fence, T
Fence Spring Assy" p.3-93
5. Check "Encoder: CR" from "Check: Test” -"Test5: Encoder"
of self-diagnosis function.
When failed:
a)Check the connection of the following locations.
• CR board Assy connector
b) Replace the following parts.
• Ｔ Fence
• CR Motor Assy
• CR Board Assy
• CR_FFC
"3.7.4 Replacing CR Board
Assy" p.3-101
"3.11.3 Replacing CR_FFC"
p.3-154
9 E081 Err
CR Origin
CR_HP cannot be
detected.
1. Check CR origin sensor in “Sen.: CR Origin” in the self-
diagnosis function.
(Check if “ON” is displayed when Carriage is locked and
“OFF” is displayed when Carriage is moved.)
Check the connection of CR origin sensor relay Assy
connector.
"5.5.4 Sensor Menu" p.5-12
2. CR origin sensor may be damaged. Replace CR origin sensor. "3.6.3 Replacing CR_HP
sensor" p.3-89
3. MAIN board Assy may be damaged. Replace MAIN board Assy "3.4.4 Replacing MAIN Board
Assy" p.3-42
No. Message Symptoms Check Item Action Reference
To Next Page
