2.2 Troubleshooting with Error Messages VJ1324E-M-02
2.2.3 Errors Requiring Reboot P.2-31
26 E144 Err
Serial WR
Failure is detected
during serial
communication
writing between
MAIN board
Assy and CR
board Assy .
1. CR FFC’s connection may be faulty or it may be damaged.
2. CR board Assy may be malfunctioning.
3. MAIN board Assy may be malfunctioning.
1. Restart the printer to see if the same error still
occurs.
<
2. Check the connection of CR FFC.
3. Replace CR FFC.
4. Replace CR board Assy .
5. Replace MAIN board Assy .
"3.11.3 Replacing CR_FFC"
p.3-154
"3.7.4 Replacing CR Board
Assy" p.3-101
"3.4.4 Replacing MAIN Board
Assy" p.3-42
27 E145 Err
Serial RD
Failure is detected
during serial
communication
reading between
MAIN board
Assy and CR
board Assy .
28 E146Err
Serial AD Cable1
An anomaly is
detected in Serial
communication
between MAIN
board Assy and
CR board Assy.
29 E147Err
Serial AD Cable2
30 E148 Err
Serial Comp
A data read in by
serial
communication
between MAIN
board Assy and
CR board Assy is
different from the
required one.
1. CR FFC’s connection may be faulty or it may be damaged.
2. CR board Assy may be malfunctioning.
3. MAIN board Assy may be malfunctioning.
1. Restart the printer to see if the same error still
occurs
2. Check the connection of CR FFC.
3. Replace CR FFC.
4. Replace CR board Assy .
5. Replace MAIN board Assy .
"3.11.3 Replacing CR_FFC"
p.3-154
"3.7.4 Replacing CR Board
Assy" p.3-101
"3.4.4 Replacing MAIN Board
Assy" p.3-42
31 E152 Err
CR Base Fuse
The power-supply
from the printer to
Colorimeter may
be disconnected.
1. The fuse of CR board Assy may be blown. 1. Replace CR board Assy. "3.7.4 Replacing CR Board
Assy" p.3-101
No. Message Symptoms Check Item Action Reference
