2.2 Troubleshooting with Error Messages VJ1324E-M-02
2.2.4 Error Messages During File Transmission P.2-33
12 Transfer failed
Block replay
timeout
Block reply
timeout is
detected during
system code
transfer.
Check the connection between HEATER CONT board Assy and
MAIN board Assy .
• Reconnect HEATER CONTROL board and MAIN
board Assy .
• Replace the cable connecting HEATER CONT
board Assy and MAIN board Assy .
•Replace HEATER CONT board Assy.
• Replace MAIN board Assy .
"3.4.7 Replacing HEATER
CONT Board Assy" p.3-46
"3.4.4 Replacing MAIN Board
Assy" p.3-42
13 Transfer failed
Block replay error
xx
Received invalid
value by block
reply during
system code
transfer.
14 Transfer failed
Final reply
timeout
Final reply
timeout is
detected during
system code
transfer.
15 Transfer failed
Final reply error
xx
Received invalid
value by final
reply during
system code
transfer.
16 Boot Transfer
failed
Opening seq.
failed
Opening
sequence of boot
code transfer
failed.
• Check the connection between HEATER CONT board Assy and
MAIN board Assy .
• Check if the green LED is on HEATER CONT board Assy is on.
• Check if the red LED is on HEATER CONT board Assy is
blinking.
• Reconnect HEATER CONT board Assy and MAIN
board Assy .
Or replace the cable connecting HEATER CONT
board Assy and MAIN board Assy .
• If the green LED is still off after turning on the
power, replace HEATER CONT board Assy .
• If the red LED is blinking and there is no problem
on the connection between HEATER CONT board
Assy and MAIN board Assy , reinstall the
firmware.
"3.4.7 Replacing HEATER
CONT Board Assy" p.3-46
"3.4.4 Replacing MAIN Board
Assy" p.3-42
"4.3 Working with MUTOH
Service Assistance Software" p.4-4
No. Message Symptoms Check Item Action Reference
