2.2 Troubleshooting with Error Messages VJ1324E-M-02
2.2.4 Error Messages During File Transmission P.2-34
17 Boot Transfer
failed
55-AA Timeout
AA did not reply
to the boot code
transfer procedure
55.
Check the connection between HEATER CONT board Assy and
MAIN board Assy .
• Reconnect HEATER CONT board Assy and
MAIN board Assy .
• Replace the cable connecting HEATER CONT
board Assy and MAIN board Assy .
• Replace HEATER CONT board Assy .
• Replace MAIN board Assy .
"3.4.7 Replacing HEATER
CONT Board Assy" p.3-46
"3.4.4 Replacing MAIN Board
Assy" p.3-42
18 Boot Transfer
failed
55-AA reply error
xx
xx replied to the
boot code transfer
procedure 55.
19 Boot Transfer
failed
End code xx
Error (xx) replied
to the end of boot
code transfer.
20 Boot Transfer
failed
Echo timeout
An echo of the
boot code transfer
procedure did not
reply.
21 Boot Transfer
failed
Echo error xx
An invalid error
(xx) of boot code
transfer procedure
replied.
22 Internal error
Parameter save
error
Parameter writing
failed.
This should not normally happen.
FROM may be damaged.
Replace MAIN board Assy .
"3.4.4 Replacing MAIN Board
Assy" p.3-42
23 Transfer failed
Wrong year xxxx
Received wrong
year data. (xxxx).
SODIMM or MAIN board Assy may be damaged. • Replace SODIMM.
• Replace MAIN board Assy .
"3.4.4 Replacing MAIN Board
Assy" p.3-42
24 Transfer failed
Wrong month xx
Received wrong
month data. (xx).
25 Transfer failed
Wrong day xx
Received wrong
date data. (xx).
26 Transfer failed
Wrong hour xx
Received wrong
time data. (xx).
27 Transfer failed
Wrong min xx
Received wrong
minute data. (xx).
28 Transfer not
ready
Transfer is not
available.
Check if the LED display on Operation panel is in standby state in
Board manager mode.
Press an arbitrary button on Operation panel to set the
panel display in the standby state, and then reinstall.
"4.3 Working with MUTOH
Service Assistance Software" p.4-4
