MUTOH ValueJet VJ-1324 - Page 85

P.3-3
VJ1324E-M-02
3.7.14 Removing Cutter Holder.................................. 3-131
3.7.15 Replacing Cutter Solenoid Assy, Cutter Solenoid
Spring Assy .....................................................3-133
3.7.16 Replacing P_EDGE Sensor Assy .................. 3-135
3.7.17 Replacing Head FG_Assy............................... 3-137
3.8 Replacing Maintenance Section ............................. 3- 138
3.8.1 Replacing Maintenance Assy.......................... 3-138
3.8.2 Replacing PumpMotor Relay Assy.................. 3-141
3.8.3 Replacing Cap Head Assy .............................. 3-142
3.8.4 Replacing Waste Fluid Sensor Cable Assy... 3-143
3.8.5 Replacing Wiper Assy ..................................... 3-144
3.8.6 Replacing Wiper Origin Sensor Cable Assy.... 3-145
3.9 Replacing Ink Supply Section Components.......... 3- 146
3.9.1 Replacing Cartridge Holder Assy .................... 3-146
3.9.2 Replacing Ink ID Board Assy、 Pressure Roller
Holder Spring Assy ..........................................3-148
3.10 Replacement of Frame Section Components........ 3- 149
3.10.1 Replacing Adsorption FAN.............................. 3-149
3.10.2 Replacing P_REAR Sensor ........................... 3-150
3.10.3 Replacing Lock Arm Assy, Lock Arm Spring Assy,
Arm Axis Assy ..................................................3-151
3.11 Replacing Cable Guide Section Components ....... 3- 152
3.11.1 Replacing Tube Fixing Clamp ......................... 3-152
3.11.2 Replace Steel Bare.......................................... 3-153
3.11.3 Replacing CR_FFC ........................................ 3-154
3.11.4 Replace Valve Solenoid
(Exploded View CR Assy2) ..............................3-158
3.11.5 Replace Solenoid Tube Assy .......................... 3-160
3.12 Replacing Accessory Unit ....................................... 3- 161
3.12.1 Replacing Waste Fluid Level Switch ,Waste Fluid
Bottle Assy .......................................................3-161
3.13 Replacing Take-Up Unit (Option) ............................ 3- 162
3.13.1 Removing Tension Arm ................................... 3-162
3.13.2 Removing Take-Up Unit .................................. 3-164
3.13.3 Removing Take-Up Unit Cover........................ 3-165
3.13.4 Replacing Scroller ........................................... 3-166
3.13.5 Replacing Take-Up Unit Control Board Assy .. 3-169
3.13.6 Replacing Take-Up ON Sensor and Take-Up OFF
Sensor ..............................................................3-176
