Product overview VJ-1324 OPERATION MANUAL
30 2.2 Names of parts and functions
(1) Operation keys
NOTE
• The operation keys are assigned with different functions and names depending on printer status
(Normal or Setup menu display).
For details about printer status, refer to "
2.3 Printer status".
No. Name Normal Setup menu display
1 [Menu] key Shifts to the Setup menu. Shifts from Setup menu display to Normal.
2 [Enter] key Restarts printing when the printing is
suspended.
•Select the menu to be set, and shifts to the
next hierarchy.
•The setting is determined and saved.
[Cutting] key Cuts the media when pressed for more than
two seconds.
—
3 [Pause] key Pauses printing. —
[Cancel] key •When printing:
When pressed for more than two seconds,
forcefully terminates printing and deletes one
file of the remaining data.
•When receiving or analyzing data:
When pressed for more than two seconds,
deletes the data already received and
analyzed.
•Returns to the previous menu hierarchy.
Changes made in the setting are discarded.
•Shifts from Setup menu display to Normal.
4 [<] key — —
[Nozzle Check] key Press and hold this key for two seconds or
more to perform Nozzle Check printing.
—
5 [>] key •Sets Cleaning Mode.
•The lamp of Cleaning Mode that you set
lights up in green.
Down the menu level in the directory tree.
[Cleaning] key When pressed for more than two seconds,
cleaning starts.
—
6[Backward↑] key Media is fed in the reverse direction. —
[+] key — •Changes to the previous item in the displayed
menu.
•The setting is changed to the reverse
direction.
•The numeric value is increased during
numerical input.
7[Forward↓] key Media is fed in the forward direction. —
[–] key — •Changes to the previous item in the displayed
setting.
•The setting is changed to the forward
direction.
•The numeric value is decreased during
numerical input.
8 [Power] key Turns the printer ON and OFF. Turns the printer ON and OFF.
To Next Page
