20 Table Dimensions & Diagrams
Base Table
Optional Vacuum Table
9 × M4 Through hole
Jig Registration Pin: 2 × φ6, 3 HIGH
* [A] Do not insert into the hole.
A
A
A
A
A
A
A
A
A
A
449
400
347
379.7
589
483
67.2 120120
183183
12
329
( 344)
4 × φ4 DRILL - φ10 CBORE, 10 DEEP
6 × M4, 8 DEEP
353 342
329
303
521
505
483
246.5 246.5
