18 Requirements for usable media
Media that meet the requirements below can be used with this printer.
• Do not use media that is sensitive to heat.
The heat given off by the UV rays could deform such media, or affect its image quality, or cause it to contact with the head.
• If printing onto a solid object that is liable to roll (such as a golf ball or ballpoint pen), use a jig or similar to stop it from
rolling.
• Printing on non-flat surface media will generate ink mist, causing malfunction or damage to the printer.
• If you are printing on non-flat surface media and there is large distance between the print head and media, you may not
be able to achieve predictable print quality.
To print on such media with more than 0.5 mm height difference, it is recommended to use the "Low Speed" printing mode.
It allows you to print on media up to 2.0 mm height difference and helps to minimize the ink mist, ink bleeding or layer shift.
"** > 6: Low Speed" P. 72
• Printing on a light reflective material may have a chance to cure the ink on the print head, causing malfunction or damage
to the product. To print on such materials, it is recommended to mask the non-print area on the material.
Requirements for usable media
Usable sizes
Maximum width 483 mm
Maximum length 329 mm
Maximum thickness 150 mm
With standard table installed 0 mm to 70 mm
With standard table removed 0 mm to 150 mm
With optional vacuum table installed 0 mm to 70 mm
Surface height
difference
approximately -0.5 mm maximum
Weight
(including jig)
With standard table installed up to 5 kg
With standard table removed up to 8 kg
With optional vacuum table installed up to 4 kg
Important!
The minimum media width and length that are settable in the User Type for the printer are 30 mm × 30 mm. To print onto media
with dimensions smaller than these, you should take precautions to prevent the table from being dirtied with ink.
Note
Contact your local MUTOH dealer about roll media recommended for your printer.
Cautions for handling media
