158 List of specifications
4 Specification s of this product
List of specifications
Model Name XPJ-461UF
Print method On demand piezo method
Drive method Firmware servo/DC motor drive
Media feed method Setting on (removing from) the table from the front, with the
front cover open
Media hold down
method
· Personal jig (it can be installed on the base table or standard
table.)
· Optional vacuum table
Ink curing device UV-LED Lamp
Conditions of usable
media
Maximum width 483 mm
Maximum length 329 mm
Maximum thickness With standard table installed: 0 mm to 70 mm
With standard table removed: 0 mm to 150 mm
With optional vacuum table installed: 0 mm to 70 mm
Weight (including jig) With standard table installed: up to 5 kg
With standard table removed: up to 8 kg
With optional vacuum table installed: up to 4 kg
Maximum print width 483 mm
Maximum print length 329 mm
Head height
adjustment
Table height adjustable by using PG handwheel. Interference
with media and/or head controlled via obstacle sensor
CPU 64bit RISC CPU
Memory 256MB
Interface Ethernet (10/100BASE-TX)
Ink Color 4 colors (Black, Cyan, Magenta, Yellow)
6 colors (Black, Cyan, Magenta, Yellow, White, Varnish)
Type 220 ml cartridge
Waste Ink Tank Fixed to the body type, capacity 2,000 ml, waste ink discharge
by users
Specifications of this product
