Table B1: Pipe Data (Continued)
OD Wall Thickness Weight Resistance Factor External Area
cm in. mm in. kg/m lb/ft µohm/m µohm/ft A/mV/m A/mV/ft m
2
/m ft
2
/ft 100 m
2
/km 100 ft
2
/mile
41 16 6.35 0.250 62.58 42.05 22.3 6.81 44.735 146.77 1.277 4.189 12.770 221.17
41 16 7.92 0.312 77.92 52.36 17.9 5.47 55.705 182.76 1.277 4.189 12.770 221.17
41 16 9.53 0.375 93.13 62.58 15.0 4.58 66.577 218.43 1.277 4.189 12.770 221.17
41 16 16.7 0.656 160.0 107.5 8.76 2.67 114.37 375.22 1.277 4.189 12.770 221.17
46 18 6.35 0.250 70.53 47.39 19.8 6.05 50.417 165.41 1.436 4.712 14.360 248.81
51 20 6.35 0.250 78.47 52.73 17.8 5.43 56.098 184.05 1.596 5.236 15.960 276.46
51 20 7.14 0.281 88.15 59.23 15.9 4.84 63.014 206.74 1.596 5.236 15.960 276.46
51 20 7.92 0.312 84.40 56.71 16.6 5.05 60.332 197.94 1.596 5.236 15.960 276.46
51 20 9.53 0.375 117 78.6 12.0 3.65 83.622 274.35 1.596 5.236 15.960 276.46
56 22 6.35 0.250 86.42 58.07 16.2 4.93 61.780 202.69 1.756 5.760 17.560 304.11
59.373 23.375 9.53 0.375 137.2 92.19 10.2 3.11 98.079 321.78 1.865 6.120 18.650 323.11
59.373 23.375 11.9 0.469 170.7 114.7 8.20 2.50 122.07 400.49 1.865 6.120 18.650 323.11
61 24 7.14 0.281 106.0 71.25 13.2 4.02 75.801 248.69 1.915 6.283 19.150 331.75
61 24 7.92 0.312 117.7 79.06 11.9 3.62 84.110 275.95 1.915 6.283 19.150 331.75
61 24 8.74 0.344 129.2 86.85 10.8 3.30 92.397 303.14 1.915 6.283 19.150 331.75
61 24 10.3 0.406 152.3 102.4 9.19 2.80 108.91 357.31 1.915 6.283 19.150 331.75
61 24 11.9 0.469 175.3 117.8 7.97 2.43 125.33 411.20 1.915 6.283 19.150 331.75
61 24 12.7 0.500 186.8 125.5 7.48 2.28 133.51 438.01 1.915 6.283 19.150 331.75
61 24 15.9 0.625 232.2 156.1 6.04 1.84 166.02 544.68 1.915 6.283 19.150 331.75
66 26 7.24 0.285 117 78.3 12.0 3.66 83.302 273.30 2.075 6.807 20.750 359.40
66 26 7.92 0.312 142.5 95.73 9.81 2.99 101.85 334.14 2.075 6.807 20.750 359.40
66 26 8.26 0.325 132.6 89.12 10.5 3.21 94.811 311.06 2.075 6.807 20.750 359.40
66 26 9.53 0.375 152.73 102.63 9.15 2.79 109.19 358.22 2.075 6.807 20.750 359.40
66 26 12.7 0.500 202.65 136.17 6.89 2.10 144.87 475.29 2.075 6.807 20.750 359.40
