RP0200-2000
20 NACE International
Table B1: Pipe Data (Continued)
OD Wall Thickness Weight Resistance Factor External Area
cm in. mm in. kg/m lb/ft µohm/m µohm/ft A/mV/m A/mV/ft m
2
/m ft
2
/ft 100 m
2
/km 100 ft
2
/mile
76 30 7.92 0.312 147.4 99.08 9.48 2.89 105.41 345.83 2.394 7.854 23.939 414.69
76 30 8.26 0.325 153.12 102.89 9.12 2.78 109.46 359.13 2.394 7.854 23.939 414.69
76 30 8.74 0.344 162.03 108.88 8.63 2.63 115.83 380.03 2.394 7.854 23.939 414.69
76 30 9.1 0.36 169.59 113.96 8.23 2.51 121.24 397.77 2.394 7.854 23.939 414.69
76 30 9.53 0.375 176.57 118.65 7.91 2.41 126.23 414.14 2.394 7.854 23.939 414.69
76 30 10.3 0.406 191.1 128.4 7.32 2.23 136.60 448.17 2.394 7.854 23.939 414.69
76 30 11.1 0.438 205.56 138.13 6.79 2.07 146.95 482.13 2.394 7.854 23.939 414.69
76 30 10 0.50 234.43 157.53 5.97 1.82 167.59 549.84 2.394 7.854 23.939 414.69
91 36 8.74 0.344 194.8 130.9 7.19 2.19 139.26 456.89 2.873 9.425 28.727 497.63
91 36 9.53 0.375 212.33 142.68 6.59 2.01 151.79 498.01 2.873 9.425 28.727 497.63
91 36 10.3 0.406 229.82 154.43 6.10 1.86 164.29 539.02 2.873 9.425 28.727 497.63
91 36 11.9 0.469 264.72 177.88 5.28 1.61 189.24 620.87 2.873 9.425 28.727 497.63
91 36 10 0.50 282.12 189.57 4.95 1.51 201.68 661.68 2.873 9.425 28.727 497.63
91 36 14.3 0.562 316.82 212.89 4.43 1.35 226.49 743.07 2.873 9.425 28.727 497.63
91 36 15.9 0.625 351.41 236.13 3.97 1.21 251.21 824.19 2.873 9.425 28.727 497.63
91 36 17.4 0.687 385.86 259.28 3.61 1.10 275.84 904.99 2.873 9.425 28.727 497.63
107 42.0 9.53 0.375 248.13 166.73 5.64 1.72 177.38 581.95 3.3516 10.996 33.516 580.57
107 42.0 9.9 0.39 257.92 173.31 5.41 1.65 184.38 604.92 3.3516 10.996 33.516 580.57
107 42.0 11.1 0.438 289.3 194.4 4.82 1.47 206.82 678.53 3.3516 10.996 33.516 580.57
107 42.0 10 0.50 329.84 221.64 4.23 1.29 235.80 773.61 3.3516 10.996 33.516 580.57
107 42.0 14.3 0.562 370.1 248.7 3.77 1.15 264.58 868.06 3.3516 10.996 33.516 580.57
107 42.0 15.9 0.625 411.07 276.22 3.41 1.04 293.86 964.12 3.3516 10.996 33.516 580.57
122 48.0 10 0.50 377.52 253.68 3.71 1.13 269.89 885.45 3.8301 12.566 38.301 663.50
122 48.0 15.9 0.625 470.67 316.27 2.99 0.910 336.472 1,103.91 3.8301 12.566 38.301 663.50
122 48.0 19 0.75 563.31 378.52 2.49 0.760 402.699 1,321.19 3.8301 12.566 38.301 663.50
