3.2 Device overview
Narda IDA-3106 25
3.2.3 Device side panel with antenna / cable
connectors
3.2.4 Device side panel with battery compartment
No. Element Function / Explanation
1 Multi-pin connector 12-pole socket for connecting the control cable (for
automatic recognition of antenna and cable when
using a Narda antenna or Narda cable).
2 N connector Antenna connecting socket
1 2
No. Element Function / Explanation
1 Battery
compartment
with lid and fixing
screw
Holds the rechargeable batteries.
1
