Native Instruments MASCHINE MK3 Getting Started

If you wish to load a Plug-in at the Group level, just follow the same procedure except at
the second step click the GROUP tab instead of the SOUND tab! Similarly, if you wish
to load a Plug-in at the Master level (to process the audio of the whole Project), click the
MASTER tab at this step.
7.1.2 Loading an Effect on the Controller
1. Press the PLUG-IN button to enter Control mode and display the Plug-in slots.
2. Press button B to select the Group “Bass” containing the bass lines.
3. Press SELECT + pad 1 to select the Sound “Analovue.”
4. Press Button 3 to select the SOUND tab.
You see the Massive Plug-in in the left display, surrounded by a white frame indicating
that the Plug-in is under focus:
5.
Move the 4-D encoder to the right (or press Button 6) to put the focus onto the “+” sym-
bol.
This selects the next free Plug-in slot.
6. Press the 4-D encoder to open the Plug-in menu. You can also press SHIFT + BROWSER
to do this.
Applying Effects
Loading Effects
MASCHINE - Getting Started - 110

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
