Native Instruments MASCHINE MK3 Getting Started

Selecting Another Snare Sample on the Controller
On your controller, do the following:
1. Press BROWSER to open the Browser.
2. Press pad 6 to select its Sound.
3. Press Button 2 above the displays repeatedly until SAMPLES is selected.
⇨ By selecting this, a list of Samples will become visible on the right display.
4. Check that Button 4 above the displays is not fully lit and that the USER label under-
neath is not highlighted; if necessary, press Button 4 to disable it.
⇨ This will select only Native Instruments factory content:
5. Move the 4-D encoder to the left or to the right in order to put the focus (indicated by the
brackets) on All Types, then turn the encoder to select the Drums type, thereby limiting
the results to the drum Samples:
You can also press and hold the 4-D encoder to temporarily display all available types; you
can even turn the encoder while pressing it to see where your selection currently is.
Building Your Own Drum Kit
Customizing Your Drum Kit
MASCHINE - Getting Started - 56

Native Instruments MASCHINE MK3 Specifications

General

Encoders	8 touch-sensitive knobs
Audio Interface	24-bit / 96 kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Pads	16 x Multi-color Pads, Velocity-Sensitive, Aftertouch
Display	2 full-color screens
Outputs	1/4" TRS Line Outputs, Stereo Headphone Output
Software	Maschine Software
Power Supply	USB bus-powered
Dimensions	320 x 301 x 41 mm
Weight	2.2 kg
System Requirements	Intel Core i5, 4 GB RAM
Inputs	1 x 1/4" TRS Mic Input, 2 x 1/4" TRS Line Inputs
