2. Setting Up Your Projector
53
Connecting the cable
In order to attach the power cable to the connector block, connect the wires using the following
procedure such that the individual wires cannot directly touch each other.
[1]
Remove the power cable sleeves
from the terminals to ensure that the
sleeves are not pinched by the
terminal attachment screw.
Pull back the sleeves from the terminal area
before fastening the screw to prevent the
sleeves from being pinched.
[2]
Attach the sleeves after tightening the
screw.
Tighten the fixing screw to the designated
torque.
Use sleeves and secure the insulation to ensure that
terminals do not touch each other. If the cables are
attached to the power supply terminal without using
sleeves, there is a risk of the terminals touching each
other as shown in the photograph on the right.
Sleeves
To Next Page
