2. Setting Up Your Projector
84
[6] Hold the lens unit with its
guide notch faced upward
and insert the lens until it
cannot go further.
Insert the holder into the fixing hole of the
lens ring and mount it with rotating it
clockwise.
Pay attention not to catch the lens control
cable here.
[7] Tighten the fixing screws (2
screws) for the lens holder.
[8] Connect the control signal
cable to the projector.
Control cable
To Next Page
