2. Setting Up Your Projector
94
While attaching the small iris, affix the top
left of the reserve tank using the tab and
support the bottom left on the fixing lug.
Note
Take care that you do not bend the connected pipes when you move the reserve tank.
[4] Remove the fixing-use
bracket.
Loosen the three screws to remove the
fixing-use bracket.
ヘッド
Rear side of
the reserve tank
Fixing-use
bracket
To Next Page
