(3) Connect the AC Cable Plug into the AC Adapter Jack on the CS firmly. Then put the AC Power Plug
into an AC outlet socket.
Connecting AC Adapter
NOTE 1: For detail of handling the AC adapter, refer to the document appended to the AC adapter (lo-
cally provided).
NOTE 2: AC adapter is used for local power supply. Switching HUB with power supply is not required.
AC CABLE PLUG
AC POWER PLUG
AC ADAPTER JACK
CS
INSTALLATION OF IP-CS
