NETGEAR FVS318N

IPv4 Firewall Protection
140
ProSafe Wireless-N 8-Port Gigabit VPN Firewall FVS318N
Figure 73.
2. Under the List of Bandwidth Profiles table, click the Add table button. The Add Bandwidth
Profile screen displays:
Figure 74.
3. Enter the settings as explained in the following table:
Table 32. Add Bandwidth Profile screen settings
Setting Description
Profile Name A descriptive name of the bandwidth profile for identification and management
purposes.
Direction From the Direction drop-down list, select the traffic direction for the bandwidth profile:
• Inbound Traffic. The bandwidth profile is applied only to inbound traffic. Specify
the inbound minimum and maximum bandwidths.
• Ou
tbound Traffic. The bandwidth profile is applied only to outbound traffic.
Specify the outbound minimum and maximum bandwidths.
• Both.
The bandwidth profile is applied to both outbound and inbound traffic.
Specify both the outbound and inbound minimum and maximum bandwidths.
