GS716Tv2 and GS724Tv3 Software Administration Manual
5-38 Managing Device Security
v1.0, July 2009
2. Click Refresh to refresh the page with the most current data from the switch.
3. Click Cancel to cancel the configuration on the screen and reset the data on the screen to the
latest value of the switch.
4. If you make changes to the page, click Apply to apply the changes to the system.
Protected Ports Membership
Use the Protected Ports Membership page to configure the ports as protected or unprotected. You
need read-write access privileges to modify the configuration.
Figure 5-23
Table
5-27. Port Security Settings Fields
Field Description
Convert Dynamic
Address to Static
Select the check box to convert a dynamically learned MAC address to a
statically locked address. The Dynamic MAC Address entries are converted to
Static MAC address entries in a numerically ascending order until the Static
limit is reached.
Table 5-28. Dynamic MAC Address Table Fields
Field Description
Port List Select the physical interface for which you want to display data.
VLAN ID Displays the VLAN ID corresponding to the Last Violation MAC address.
MAC Address Displays the MAC addresses learned on a specific port.
