IP Binding Table
Use the IP Binding Table page to view or delete the IP ACL bindings.
To display the IP Binding Table:
1. Click Security  ACL, then click the Advanced  Binding Table link.
2. To delete the binding, select the check box next to the interface and click Delete.
3. Click Cancel to cancel the configuration on the screen and reset the data on the screen to the
latest value of the switch.
Figure 5-34
Table 5-38. IP ACL Binding Table Fields
Field Description
Interface Shows the interface to which the IP ACL is bound.
Direction Specifies the packet filtering direction for ACL. The only valid direction
is Inbound, which means the IP ACL rules are applied to traffic entering
the port.
ACL Type Displays the type of ACL assigned to selected interface and direction.
ACL ID Displays the ACL Number identifying the ACL assigned to selected
interface and direction.
Seq No. Displays the Sequence Number signifying the order of specified ACL
relative to other ACLs assigned to selected interface and direction.
