GS716Tv2 and GS724Tv3 Software Administration Manual
3-14 Configuring Switching Information
v1.0, July 2009
4. Click Cancel to cancel the configuration on the screen and reset the data on the screen to the
latest value of the switch.
5. If you make any changes to this page, click Apply to send the updated configuration to the
switch. Configuration changes take place immediately.
Port VLAN ID Configuration
Use the Port VLAN ID (PVID) Configuration page to configure a virtual LAN on a port.
To access the Port PVID Configuration page:
1. Click Switching VLAN Advanced Port PVID Configuration in the navigation tree.
Untagged/Tagged Port
Members
Click Untagged Port Members or Tagged Port Members to see the port
list and use it to add the ports you selected to this VLAN. Each port has
three modes:
• Tagged: Select the ports on which all frames transmitted for this
VLAN will be tagged. The ports that are selected will be included in
the VLAN.
• Untagged: Select the ports on which all frames transmitted for this
VLAN will be untagged. The ports that are selected will be included in
the VLAN.
VLAN Type This field identifies the type of the VLAN you selected. Possible values
are:
• Default: The default (VLAN ID = 1) is always present.
• Static: A VLAN that you have configured using this screen.
Table 3-8. VLAN Membership Configuration Fields (continued)
Field Description
