GS716Tv2 and GS724Tv3 Software Administration Manual
6-12 Monitoring the System
v1.0, July 2009
2. Click Clear to clear all the counters. This resets all statistics for this port to the default values.
3. Click Refresh to refresh the data on the screen and display the most current statistics.
EAP Statistics
Use the EAP Statistics page to display information about EAP packets received on a specific port.
To display the EAP Statistics page:
1. Click the Monitoring Ports tab, and then click the EAP Statistics link.
Single Collision Frames A count of the number of successfully transmitted frames on a particular
interface for which transmission is inhibited by exactly one collision.
Multiple Collision Frames A count of the number of successfully transmitted frames on a particular
interface for which transmission is inhibited by more than one collision.
Excessive Collision Frames A count of frames for which transmission on a particular interface fails
due to excessive collisions.
Port Membership Discards The number of frames discarded on egress for this port due to egress
filtering being enabled.
STP BPDUs Received Number of STP BPDUs received at the selected port.
STP BPDUs Transmitted Number of STP BPDUs transmitted from the selected port.
RSTP BPDUs Received Number of RSTP BPDUs received at the selected port.
RSTP BPDUs Transmitted Number of RSTP BPDUs transmitted from the selected port.
MSTP BPDUs Received Number of MSTP BPDUs received at the selected port.
MSTP BPDUs Transmitted Number of MSTP BPDUs transmitted from the selected port.
802.3x Pause Frames
Transmitted
A count of MAC Control frames transmitted on this interface with an
opcode indicating the PAUSE operation. This counter does not
increment when the interface is operating in half-duplex mode.
EAPOL Frames Received The number of valid EAPOL frames of any type that have been received
by this authenticator.
EAPOL Frames
Transmitted
The number of EAPOL frames of any type that have been transmitted
by this authenticator.
Time Since Counters Last
Cleared
The elapsed time, in days, hours, minutes, and seconds since the
statistics for this port were last cleared.
Table 6-3. Port Detailed Statistics Fields (continued)
Field Description
