GS716Tv2 and GS724Tv3 Software Administration Manual
5-42 Managing Device Security
v1.0, July 2009
MAC Rules
Use the MAC Rules page to define rules for MAC-based ACLs. The access list definition includes
rules that specify whether traffic matching the criteria is forwarded normally or discarded. A
default 'deny all' rule is the last rule of every list.
To display the MAC Rules page:
1. Click Security ACL, then click the Basic MAC Rules link.
Figure 5-26
Table 5-31. MAC ACL Rule Configuration Fields
Field Description
ACL Name Specifies an existing MAC ACL. To set up a new MAC ACL use the
“MAC ACL” page.
ID (1 to 10) Enter a rule ID.
Action Specify what action should be taken if a packet matches the rule's
criteria:
• Permit: Forwards packets that meet the ACL criteria.
• Deny: Drops packets that meet the ACL criteria.
