GS716Tv2 and GS724Tv3 Software Administration Manual
6-6 Monitoring the System
v1.0, July 2009
Figure 6-3
Table 6-3. Port Detailed Statistics Fields
Field Description
Interface Use the drop down menu to select the interface for which data is to be
displayed or configured.
MST ID Displays the created or existing MSTs.
ifIndex This field indicates the ifIndex of the interface table entry associated
with this port on an adapter.
Port Type For most ports this field is blank. Otherwise the possible values are:
• Mirrored: Indicates that the port has been configured as a monitoring
port and is the source port in a port mirroring session. For additional
information about port monitoring and probe ports, see “Multiple Port
Mirroring” on page 6-23.
• Probe: Indicates that the port has been configured as a monitoring
port and is the destination port in a port mirroring session. For
additional information about port monitoring and probe ports, see
“Multiple Port Mirroring” on page 6-23.
• Port Channel: Indicates that the port has been configured as a
member of a port-channel, which is also known as a link Aggregation
Group (LAG).
