3.
Enter the router admin user name and password.
The user name is admin. The password is the one that you specified when you set
up your router. The user name and password are case-sensitive.
The BASIC Home page displays.
4.
Select ADVANCED > Advanced Setup > Ethernet Settings
The Ethernet Settings page displays.
In the LAN Port Aggregation section, the Ethernet Port Aggregation Status field
shows whether port aggregation is active:
•
Inactive: No link aggregation LAN device is connected to Ethernet LAN ports 1
and 2 on your router.
•
Active: A link aggregation LAN device is connected to Ethernet LAN ports 1 and
2 on your router.
5.
To change the LAN port aggregation mode, select one of the following radio buttons:
• Disable: This mode is selected by default. This mode disables LAN port
aggregation on your router. LAN ports 1 and 2 can be used as independent
Ethernet LAN ports.
• Enable (LACP-IEEE 803.3ad): After you connect the Ethernet cables, the router
communicates with the LAN device that is connected to LAN ports 1 and 2 on
your router, and checks to see if LAN port aggregation is supported on the LAN
device. If LAN port aggregation is supported, the router automatically trunks LAN
ports 1 and 2. If not, LAN ports 1 and 2 work as independent LAN ports. We
recommend that you select this mode unless your LAN device can support a static
link aggregation group (LAG) only.
• Static: If your device supports a static LAG only, select this mode. Otherwise, we
recommend that you select the Enable (LACP-IEEE 802.3ad) radio button instead.
NOTE: You must also enable link aggregation on your router before
you connect your device to LAN ports 1 and 2 on the router, otherwise
you will create a network loop.
6.
If you made changes, click the Apply button.
Your settings are saved.
User Manual115Manage the WAN and LAN
Network Settings
Nighthawk WiFi 7 Tri-Band Router Model RS700
