82Computer Integration
Quad Cortex features 16 USB channels (8 INPUTS / 8 OUTPUTS).
USB Channels
HOST USB
CHANNEL
DESCRIPTION
QUAD CORTEX
USB CHANNEL
INPUT 1 DI signal from analog OUTS 1/2 to host (non-selectable
on The Grid). Select INPUTS 1/2 on your host to record DI
tracks.
OUTPUT 1
INPUT 2 OUTPUT 2
INPUT 3 Manual route from The Grid’s output blocks to the host.
Select INPUTS 3/4 on your host to route signal from the
The Grid’s output.
OUTPUT 3
INPUT 4 OUTPUT 4
INPUT 5 Manual route from The Grid’s output blocks to the host.
Select INPUTS 5/6 on your host to route signal from The
Grid’s output.
USB OUT 5
INPUT 6 USB OUT 6
INPUT 7 Manual route from The Grid’s output blocks to the host.
Select INPUTS 7/8 on your host to route signal from The
Grid’s output.
USB OUT 7
INPUT 8 USB OUT 8
OUTPUT 1
Playback from the host through XLR Outputs (non-
selectable on The Grid) Select Outputs 1/2 on your host
to hear playback through Quad Cortex’s OUTPUTS 1/2 or
HP OUT.
INPUT 1
OUTPUT 2 INPUT 2
OUTPUT 3 Playback from the host through TRS Outputs (non-
selectable on The Grid). Select OUTPUTS 3/4 on your host
to hear the signal through Quad Cortex’s OUTPUTS 3/4.
INPUT 3
OUTPUT 4 INPUT 4
OUTPUT 5 Manual route from the host to Quad Cortex’s input blocks.
Select OUTPUTS 5/6 on your host to route the signal to a
row in The Grid.
USB IN 5
OUTPUT 6 USB IN 6
OUTPUT 7 Manual route from the host to Quad Cortex’s input blocks.
Select OUTPUTS 7/8 on your host to route the signal to a
row in The Grid.
USB IN 7
OUTPUT 8 USB IN 8
Use the Dry/Wet Switch in the I/O Settings menu to swap between clean
DIs or processed signal fed into USB OUTPUTS 1-2 or 3-4.
Dry/Wet swap via I/O Settings
