Quick Start 1
Cabling Requirements 1
• DAW Interface Outputs (Input A) - 25-Pin D-Sub > D-Sub loom x3
• Line Inputs (Input B) - ¼’’ TRS Jack 1-24
• Direct outputs - 25-Pin D-Sub > D-Sub Loom x 3
• Insert send/Return - ¼’’ TRS Jack 1-24
• Group insert Send/Return – ¼’’ TRS Jack 1-4
• Mix/Aux/Cue/Group output – XLR x9
• loudspeaker Outputs – XLR x6
• Reverb returns/EXT/500 series/1073 inputs – XLR x10
Boot Mode 1
Upon start-up, the 8424 is configured with all channel inputs on Input B.
This can be changed by switching the inputs individually on each channel, or
by pressing the global A/B CH IP switch in the master select section of the
console. Green LED’s indicate Input A state, Yellow indicate Input B.
To protect the system from feedback, the direct outputs from the channels
are fed from Input B by default. This can be changed in the services screen
by selecting MAST> IPA DIR [Y].
The console will always boot up in safe mode. This state ensures that no
damage incurs to loudspeakers or additional studio equipment on start-up.
In safe mode all feeds to speakers will be CUT (speaker outs will illuminate
RED to indicate CUT state). The control room monitor level should also be
turned fully down automatically to further protect studio equipment.
Connecting the console 1
Connect DAW interface outputs into the 8424 channel Inputs A via
the three D-sub connectors 1>8 9>16 17>24.
Connect line level instruments or external preamps into the 8424
channel inputs B where required. 1>24 ¼’’ Jack.
Connect channel Direct Outputs 1-24 to DAW interface inputs via
the D-sub connector 1>8 9>16 17>24.
Connect MIX O/P L and MIX O/P R into your DAW interface to
record your Stereo Mix back into the DAW.
Connect group 1-4 outputs GRP1 OUTPUT 1-4 into your DAW
interface if required.
Connect Aux outputs AUX O/P 1-3 to external FX units.
Connect external FX returns to Reverb Returns REV1 and REV2 L+R.
Connect Headphones to EHP1 and EHP2
Connect headphone amplifiers to CUE O/P L+R if required.
Connect studio speakers to A LS O/P Left and Right XLR.
Connect additional studio Speakers to M1 LS O/P Left and Right XLR.
Connect any analogue hardware inserts to each channel or group
using the ¼’’ jack connectors at the rear of the console.
Connect analogue hardware inserts to the master channels using
the XLR connectors at the rear of the console MIX INS SEND and
MIX INS RETURN.
