Master Controls 1
The 8424 Master controls enable global switching of channel, solo and
channel/cue input settings.
SOLO SAFE 1
Globally switches all channels and groups from SIP (Solo In Place) to non-
destructive AFL/PFL (After-fader Listen or Pre-fader listen) mode. When solo
safe is Illuminated, any solo button on the channels and groups becomes
non-destructive AFL/PFL.
RESET 1
Wipes any active console solo, does not affect ISO.
48 MIX 1
A unique 8424 function that enables 48 individual inputs to be mixed
through the console simultaneously. Pressing 48 MIX changes several
routing options on the console.
• All channel CUE inputs are set to I/P C
• All CUE sends are switched ON
• The SIP Solo system is linked to the CUE along with the channel
faders.
• CUE BUS is selected, routing all channel CUES to the Stereo Mix bus.
The console is now set to receive and mix up to 48 DAW interface outputs
through its Stereo Mix bus with inputs 1-24 appearing on the channel faders
and pan controls and inputs 25-48 appearing on the CUE level and pan
controls.
More information on 48 Mix mode can be found on Page 53.
AUX ON/PRE 1
When illuminated pressing each AUX master knob now globally
toggles all channel AUX’s 1, 2, 3 or ST CUE on or off. When illuminated
, pressing each AUX master knob now globally toggles the selected
channel AUX’s 1, 2, 3 or ST CUE between Post-fader and Pre-fader state.
IPC MTR 1
This function allows for accurate metering of all Input C (DAW inputs 25-48).
IPC MTR Globally switches the 8424 channels 8-stage LED Meters to display
Input C DAW Interface Outputs 25-48 incoming levels.
A/B CH IP 1
This function globally selects the channel inputs from either Input A (DAW
interface outputs 1-24 or Input B channel Line inputs. Global switching
functions in the same way as local A/B switching.
