Neve 8424 - Stereo Mix Output and Fader; Mix Output Path and Master Fader Control

36
PRE- sets the Master mix hardware insertion point to pre fader (see table
below)
Stereo Mix Output Signal Path 1
Master Fader 1
The 8424 Stereo Mix fader is a 100mm precision stereo fader that controls
both the Left and Right outputs of the console.
The master CUT will mute the master mix bus from the control room
monitor audio path.
If PRE is selected
If PRE not selected
500 series units
500 series units
Hardware insert
2 band EQ
2 band stereo EQ
Stereo Width Control
Stereo width control
Master Cut
Master Cut
Master Fader
Master Fader
Hardware insert
Mix O/P L/R XLR
Mix O/P L/R XLR
