Neve 8424 - Channel Input A Pin Outs

64
Channel Input A/DAW Returns 1-24 D-Type 25-Way Pin Outs
CH DAW RET I/P A 1-8 (25-way D-type)
Signal
Name
Pin
Hi
Lo
Screen
1
I/P A Input 1/DAW Return 1
24
12
25
2
I/P A Input 2/DAW Return 2
10
23
11
3
I/P A Input 3/DAW Return 3
21
9
22
4
I/P A Input 4/DAW Return 4
7
20
8
5
I/P A Input 5/DAW Return 5
18
6
19
6
I/P A Input 6/DAW Return 6
4
17
5
7
I/P A Input 7/DAW Return 7
15
3
16
8
I/P A Input 8/DAW Return 8
1
14
2
CH DAW RET I/P A 9-16 (25-way D-type)
Signal
Name
Pin
Hi
Lo
Screen
1
I/P A Input 9/DAW Return 9
24
12
25
2
I/P A Input 10/DAW Return 10
10
23
11
3
I/P A Input 11/DAW Return 11
21
9
22
4
I/P A Input 12/DAW Return 12
7
20
8
5
I/P A Input 13/DAW Return 13
18
6
19
6
I/P A Input 14/DAW Return 14
4
17
5
7
I/P A Input 15/DAW Return 15
15
3
16
8
I/P A Input 16/DAW Return 16
1
14
2
CH DAW RET I/P A 17-24 (25-way D-type)
Signal
Name
Pin
Hi
Lo
Screen
1
I/P A Input 17/DAW Return 17
24
12
25
2
I/P A Input 18/DAW Return 18
10
23
11
3
I/P A Input 19/DAW Return 19
21
9
22
4
I/P A Input 20/DAW Return 20
7
20
8
5
I/P A Input 21/DAW Return 21
18
6
19
6
I/P A Input 22/DAW Return 22
4
17
5
7
I/P A Input 23/DAW Return 23
15
3
16
8
I/P A Input 24/DAW Return 24
1
14
2
