Dimensions & Power Requirements 1
Console Physical / Technical Information
Height
To top of LS Shelf (No Stand)
500mm/19.68 inches
Height
To Top of LS Shelf (With Stand)
990mm/38.98 inches
Width (24 Channel)
1190mm/46.85 inches
Depth (24 Channel)
850mm/33.46 inches
Weight (no stand)
53kg
Weight (with stand)
64kg
Console Weight (with packaging)
84kg
Stand weight (with packaging)
12kg
Heat Dissipation
225 watts
Power factor
>0.87
Voltage
Input Voltage Range
90-240v AC Only
Current
Amps RMS 240v
1.1A
Current
Amps RMS 90v
2.3A
Current
Switch-On surge current - 4 amps for 7ms
(average)
Fuse Ratings
AC Fuses
Main IEC input fuse
T4.0A H250v
DC Fuses
+16V
T6.3A 250v
-16V
T6.3A 250v
+5V
T16A 250v
+48V
T500mA 250v
