50
Example Application - Mixing 1
The primary input for mixing is Input A. This is fed via D-type connections directly into the console from the DAW
Audio Interface. When 24 DAW outputs are connected via the consoles three Input A D-type connectors, 24
separate channels of audio can be mixed through the consoles Stereo Mix Bus, through the 4 Mono Group busses
through the Group direct outputs, or bounced as individual stems back into the DAW by using the channel Direct
Outputs. The 8424 has Marinair® Transformers on its Stereo Mix bus for true Voltage mixing. The processing on the
master section of the console (Group/Stereo Mix EQ’s, Stereo width control, Channel, Group or master hardware
inserts, 500 series inserts) allow for versatile tone shaping of Group signals and the main Stereo Mix signal. If your
session requires more than 24 mix channels, there is no need to sum multiple DAW channels into console stereo
pairs. The consoles 48 MIX mode gives the capability of mixing 48 separate channels simultaneously through the
console. DAW interface Outputs 25-48 can be fed from the Audio Interface into the Input C D-Type connectors on
the rear of the console.
More Information on 48 Mix Mode is found
on page 53.
