8424 Audio Specification 1
Line Input B to Direct Output
Headroom
+27.7dBu @ 1kHz (<0.5% THD+N)
Frequency Response
Typically +/- 0.1dBu, 20Hz to 20kHz
Distortion (THD+N)
Typically 0.004% @ 1kHz (measured at +10dBu 10Hz to 80kHz filter)
Noise
<-88dBu (20Hz to 22kHz filter)
Input C to Cue Bus Output
Headroom
+27.6dBu @ 1kHz (<0.5% THD+N)
Frequency Response
Typically +/- 0.1dBu, 20Hz to 20kHz
Distortion (THD+N)
Typically 0.005% @ 1kHz (measured at +20dBu, 10Hz to 80kHz filter)
Noise
<-86dBu (20Hz to 22kHz filter)
1073 Input to 1073 Output
Headroom
+28.8dBu @ 1kHz (<0.5% THD+N)
Frequency Response
Typically +/- 0.1dB, 20Hz to 20kHz
Distortion (THD+N)
Typically 0.005% @ 1kHz (measured at +20dBu, 10Hz to 80kHz filter)
Noise (EIN)
<-125.5dBu (20Hz to 22kHz filter, 60dB gain, input terminated 150Ω R)
Line B to Mix Output
Headroom
+27.4dBu @ 1kHz (<0.5% THD+N)
Frequency Response
Typically +/- 0.1dBu, 20Hz to 20kHz
Distortion (THD+N)
Typically 0.004% @ 1kHz (measured at +10dBu, 10Hz to 80kHz filter)
Noise
<-85dBu (20Hz to 20kHz filter, no channel routed)
<-84dBu (20Hz to 22kHz filter, 1 channel routed)
<-80dBu (20Hz to 22kHz filter, 24 channels routed)
Line B to Group Mix Output
Headroom
+27.8dBu @ 1kHz (<0.5% THD+N)
Frequency Response
Typically +/- 0.1dBu, 20Hz to 20kHz
Distortion (THD+N)
Typically 0.005% @ 1kHz (measured at +20dBu, 10Hz to 80kHz filter)
Noise
<-90dBu (20Hz to 22kHz filter, no channel routed)
<-87dBu (20Hz to 22kHz filter, 1 channel routed)
Line B to Aux Mix Output
Headroom
+27.8dBu @ 1kHz (<0.5% THD+N)
Frequency Response
Typically +/- 0.1dBu, 20Hz to 20kHz
Distortion (THD+N)
Typically 0.003% @ 1kHz (measured at +20dBu, 10Hz to 80kHz filter)
Noise
<-92dBu (20Hz to 22kHz filter, no channel routed)
<-88dBu (20Hz to 22kHz filter, 1 channel routed)
