500 series slots 1
Overview 1
500-series is a module size that AMS-Neve and many other pro audio
companies manufacture modules for. All 500 series modules that are VPR
Alliance approved will work perfectly in the 8424 500 series slots. The 8424
console has 2 empty slot that can be filled with any 500 series outboard
units and used on a variety of console signals.
500 Series Routing 1
The two 500 series units can be routed as inserts to any of the following-
• 4 mono sub-group Inserts (pre-processing)
Press the 500-1 or 500-2 button above the selected group
fader to use the 500 series module as a group insert.
• Stereo Master Inserts (pre-processing)
Press the 500-1/2 button above the stereo master fader to
use both of the 500 series modules as a stereo Master
Insert.
• 2 built in 1073 microphone/line preamp inserts. (Post gain & trim)
Press the 500-1 or 500-2 button at the bottom of the 1073
preamp section to use as an insert for the selected preamp
channel (before smart routing to channels 17/18)
• 2 built in Instrument D.I inputs. (Post-level control)
Press the 500-1 or 500-2 button at the bottom of the
Instrument DI section to use as an insert for the selected
Instrument D.I. (before smart routing to channels 19/20)
Direct Input/Output 1
In addition to the group, mix, preamp and DI routing options, the 8424 500
series units can be used as standalone hardware units by using the XLR
in/out connections on the rear of the console. This allows the 500 series
slots to function as a separate hardware rack, independent of the console.
The outputs of the standalone 500 series units can also be routed to any
channel on the console by using a physical XLR>¼’’ TRS Line connection.
Caution: if preamplifiers are used in the 8424 500 series slots, do not
activate group, Stereo Mix, 1073 or Instrument DI 500 1/2 buttons.
