Neve 8424 - Connector Pin Out Functions; Line;XLR Wiring and DC Remote Pin Outs; VU Meter, OSC, and TB Pin Out Functions

67
Line Inputs & Outputs
All ¼’’ Line Inputs & Outputs on the Console have the same wiring
Tip
Hot
Ring
Cold
Sleeve
Ground
XLR Inputs & Outputs
All XLR Inputs & Outputs on the Console have the same wiring
Pin 2
Hot
Pin 3
Cold
Pin 1
Ground
DC remote Pin Out Functions
(15-way D-type)
Pin 1
Producers Sofa Mic Remote Talkback
Pin 2
Remote Loudspeaker Dim
Pin 3
Remote Loudspeaker Cut
Pin 4
Engineers Talkback Footswitch
Pin 5
5v Supply for Producer talkback switch
Pin 6
5v Supply for Producer talkback switch
Pin 7
Not in Use
Pin 8
Not in Use
Pin 9,10,11,12
Not in Use
2T VU MTR Pin Out Functions
(15-way D-type)
Signal
Name
Pin
Hi
Lo
Screen
1
VU Meter 1
7
15
8
2
VU Meter 2
13
6
14
3
Not in Use
5
4
12
4
Talkback Output
1
9
2
5
+4dB Oscillator Output
10
3
11
