4.1 Measuring with Constant Voltage or Current (ALC)
4-3 ZM2376
When ALC function is enabled, “c” is displayed before the measurement signal level.
• • • • • • • 1.00000M Measurement frequency Hz
• • • • • • • c1.00 V Voltage Vrms
• • • • • • • c1.00mA Current Arms
With the constant voltage function enabled, if the DUT is removed after small
impedance was measured, the maximum 5Vrms signal may be output.
With the constant current function enabled, if the measurement terminals are
opened, the maximum 5Vrms signal may be output.
Current: The current setting menu is as follows.
Current: 1.00mA Current setting
0.0010mA to 200mA Available value ranges
The setting resolution is 3 digits (0.1µA when < 10µA).
If a setting is made or the EXIT operation is performed, one-previous menu comes back.
