1.1 Features
The “ZM2376 LCR Meter” is a high speed LCR meter with the maximum frequency 5.5MHz and
maximum signal level 5V. It has high basic accuracy of 0.08% and is capable of measuring the impedance
in a wide application range from manufacturing and inspection lines of electronic parts up to the research
of materials.
 Measurement frequency 1mHz to 5.5MHz
The instrument has the maximum 6-digit resolution and thus it is capable of measuring the detailed
frequency characteristics of the DUT (Device Under Test).
 Signal level 10mV to 5V / Maximum current 200mA
It is capable of measuring the characteristics of DUT in a wide signal level range.
 Constant voltage / Constant current drive
It can make evaluation on stable signal level even for the DUT of which characteristics vary with
the signal level.
 High speed measurement
It provides high speed measurement at the fastest 2ms (1kHz - 1MHz) or 10ms (120Hz).
 Cable length 0m / 1m / 2m / 4m
Allowable length of connection cable to the DUT is maximum 4m. However, it is limited by the
frequency.
 Triggered drive
A signal is output after the instrument contacted the DUT, thus reducing the contact damage when
high capacitance capacitor is measured. Also, this feature reduces measurement dispersion of the
DUT having hysteresis characteristics.
 Contact check
A contact failure to DUT can be detected based on an abnormally low capacitance or abnormal
voltage/current signal, with little additional time required.
 Handler interface
The bin sorting results of maximum 14 categories can be output to the part handler.
 Remote control
The instrument is equipped with the USB, RS-232 (230.4kbps max), and GPIB interfaces as
standard, which is useful for installing it in production lines or measurement systems. A LAN
interface is also available optionally.
