2.2 Installation
2-7 ZM2376
This product may cause interference if used in residential areas. Such use must
be avoided unless the user takes special measures to reduce electromagnetic
emissions to prevent interference to the reception of radio and television
broadcasts.
2.2.3 Rack Mounting
ZM2376 can be mounted on a 19-inch IEC rack, an EIA specification rack or a JIS specification rack
by the use of a rack-mount adapter (optional). The rack-mount adapter is provided for mm-rack and
inch-rack.
First, mount the rack-mount adapter on the device as shown in “Figure 2-1 Rack-mount assembly
(mm-rack)” or “Figure 2-2 Rack-mount assembly (inch-rack)”, and then, mount the instrument on the
rack.
When mounting the instrument on the rack, be sure to install rack rails to support
the ZM2376. Otherwise, ZM2376 may fall, causing a human injury.
• When mounting the instrument on the rack, be sure to install rack rails to
support the ZM2376. Otherwise, ZM2376 may fall, causing a product damage.
• Make sure that the rack is sufficiently air-cooled by providing appropriate
ventilation ports or cooling fans.
• The air inlet of ZM2376 is provided on both side panels.
Ensure 20mm or more clearance between side panel and wall.
• The air outlet is provided on the rear panel.
Ensure 50mm or more clearance between rear panel and wall.
Higher ambient temperature than the specification or blocking the air inlet or
outlet may reduce the performance or damage the ZM2376.
