NF ZM2376 - 4.14 Initializing of All Settings

4.14 Initializing of All Settings
4-56 ZM2376
4.14 Initializing of All Settings
ZM2376 can be initialized in some levels.
 Initializing the current setting while the contents of setting/correction value memory are
being left over
_SHIFT_ + [ INIT ]
Press the _SHIFT_ + [INIT] keys to display the initializing menu.
INITIALIZE
1)Execute Options
Done Completion message
Press the _1_ key and select the Execute, and the current setting and correction value return to the
initial values.
After execution, the completion message appears for a short time and measurement screen comes
back.
The following setting cannot be initialized but retained:
1) Contents of setting/correction value memory
2) Frequency and setting memory specified in the multi-measurement list
3) Setting of interface (GPIB, RS-232, USB, and LAN)
4) Trigger polarity of handler interface
_0_ | [INIT]
_SHIFT_
