5.1 Error Message
5-5 ZM2376
5.1.3 Errors During Measurement
Main error messages displayed during measurement or during measurement of correction values are
as listed below.
•When trigger source is INT (internal),
an attempt to apply other trigger
was made and thus that trigger was
ignored.
Set the trigger source correctly
according to actual trigger signal.
•Though the device does not wait for
trigger, an attempt to apply the
trigger was made and thus that
trigger was ignored. Possible
causes will be as follows:
1) During the measurement, the trigger
is not accepted.
2) If *RST command is executed,
continuous initiation is disabled, and
thus the trigger immediately after
that is not accepted.
For the operation from the panel, press
the _SHIFT_ + [INIT] keys and then the
_1_
key to execute initialization.
For the operation from remote control,
1) Send :ABORT command to abort
the measurement once.
2) Send :INIT:CONT ON command
or :INIT command to place the
device in trigger waiting state.
•The device is in overheating state,
and thus the trigger was ignored.
Allow time until internal temperature
lowers sufficiently, and reset the error.
OPEN, SHORT, LOAD correction
values could not be measured.
Perform usual measurement to check
the condition where measurement failed,
and then remove a problem.
•As the measurement impossible state
lasts for a long time, the
measurement was terminated
forcibly.
Main cause is large external noise or
electrostatic discharge.
Install device or cables that generate
large noise away from the LCR meter.
Beware of charged device or human
body so as not to discharge to the LCR
meter during measurement.
Over
Temperature
(Tripped)
•Overheat was detected.
The drive signal level becomes
zero, disabling new measurement.
Main causes will be as follows:
1) The impedance below 1Ω was
measured for a long time at a
place of high ambient temperature.
2) Cooling fan is defective.
Remove a cause of overheat, and then
allow time until internal temperature
lowers sufficiently, and reset the error.
1) Restrain the internal temperature
by lowering the ambient
temperature or executing
intermittent measurement by
triggered drive.
2) Please ask NF Corporation or one
of our representatives for repair.
Over
Temperature
(Removed)
•Though overheat was detected, the
temperature has already lowered at
which the device can operate.
Press the _ENTR_
| [EXIT] key to reset
this message and the device will be
recovered to usual operation.
Other error message may be displayed according to the situations.
For warning messages displayed due to various operations, see the description of each operation.
